3.2.9 -

DATA

MODE

Data

mode gathers a set of data about

the operation state of the boiler and of

each thermal element. By using the

step

key it is possible to scroll all values. The

table here below shows the data con-

tents concerning the whole boiler. When

entering the service code, all other data

(from 1 to 7 burners) are also program-

mable.

Data Data ref. Signification Unit

series

Data 1 Local flow temperature, NTC1 °C

relevant 2 Local flow temperature, NTC2 °C

to bur.1 3* Thermal element 1 fan speed adjustment 1 rpm xxxx

4* Thermal element 1 actual fan speed 1 rpm xxxx

Data 1 Local flow temperature, NTC2 °C

relevant 2 Local flow temperature, NTC3 °C

to bur.2 3* Thermal element 1 fan speed adjustment 2 rpm xxxx

4* Thermal element 1 actual fan speed 2 rpm xxxx

Data 1 Local flow temperature, NTC3 °C

relevant 2 Local flow temperature, NTC4 °C

to bur.3 3* Thermal element 1 fan speed adjustment 3 giri/min xxxx

4* Thermal element 1 actual fan speed 3 giri/min xxxx

Data 1 Local flow temperature, NTC4 °C

relevant 2 Local flow temperature, NTC5 °C

to bur.4 3* Thermal element 1 fan speed adjustment 4 rpm xxxx

4* Thermal element 1 actual fan speed 4 rpm xxxx

Data 1 Local flow temperature, NTC5 °C

relevant 2 Local flow temperature, NTC6 °C

to bur.5 3* Thermal element 1 fan speed adjustment 5 rpm xxxx

4* Thermal element 1 actual fan speed 5 rpm xxxx

Data 1 Local flow temperature, NTC6 °C

relevant 2 Local flow temperature, NTC7 °C

to bur.6 3* Thermal element 1 fan speed adjustment 6 rpm xxxx

4* Thermal element 1 actual fan speed 6 rpm xxxx

Data 1 Local flow temperature, NTC7 °C

relevant 2 Local flow temperature, NTC8 °C

to bur.7 3* Thermal element 1 fan speed adjustment 7 rpm xxxx

4* Thermal element 1 actual fan speed 7 rpm xxxx

Data Data ref. Signification Unit

series

Data 1 Global flow temperature °C

relevant 2 Global return temperature °C

to the whole 3 DHW temperature °C

boiler 4 Outer temperature °C

5 Smoke temperature (not implemented) °C

6 Flow temperature adjustment °C

7 * Fan speed adjustment rpm xxxx

8 Output calculated in % (on the complete boiler) % xxxx

* Note: The parameter figure is not displayed

3.2.9.1 - OPERATION PARAMETERS ACCESSIBLE TO INSTALLER AND USER

3.2.9.2 - PARAMETERS ACCESSIBLE ONLY TO THE INSTALLER BY PREVIOUSLY ENTERING THE SERVICE CODE
