Unical modulex 360 User Manual

7
1.2 - DIMENSION
fig. 1-a
REAR VIEW
UPPER VIEW
L.H. SIDE VIEW
FRONT VIEW
MODULEX 360
®
1243
576
S
T
O
R
E
M
O
D
E
R
E
S
E
T
S
T
E
P
920
S
B
A
C
206
171
1372
666
232
474
974
398
R
M
G
474
446
Øi D
110
124
H
MODULEX
Dimension
No. of Modules
Height mm
Width ''L'' net mm
Width with packaging mm
Depth ''C'' mm
Depth ''A'' mm
Depth ''B'' mm
Depth with packaging mm
Net weight kg
Gross weight kg
Connections
Gas mm
C.H. system Flow M mm
C.H. system Return R mm
Chimney connection ''D'' mm
Chimney width ''H'' mm
Condensate drain diameter mm
360
4
1372
920
1020
1530
985
390
1200
430
496
DN50 PN 10/16
DN80 PN 10/16
DN80 PN 10/16
250
615
40
ATTENTION
CHIMNEY
CONNECTION
INDIFFERENT
POSITION FROM THE
ONE SHOWN ARE
NOT ALLOWED.
