INSTRUMENTS AND CONTROLS
2-17
LIGHTS AND LAMPS
CAUTION
Check that lights and lamps come on
and off properly. If any light bulb is
blown out, replace with a new one. If
the lens is contaminated or damaged,
clean or repair.
Front side
The truck has head lamps and front
combination lamps (turn signal and
clearance lamps) at its front side.
Rear side
The truck has rear combination lamps (tail
lamps, brake lamps, back-up lamps, turn
signals and rear reector) at its rear.
The license number plate lamp is optionally
available.
SIDEVIEW MIRRORS AND UNDER-
MIRROR
CAUTION
•
When traveling in reverse, always
look in the direction of travel. Do
not rely too much on the sideview
mirrors.
•
Keep the mirror surfaces always
clean.
•
Adjust the sideview mirrors to gain
full rear vision.
The sideview mirrors are provided on the
front poles of the overhead guard, one for
each.
The under-mirror is installed on the counter-
weight.
HEAD
LAMP
HEAD
LAMP
COMBINATION LAMP
COMBINATION
LAMP
