INSTRUMENTS AND CONTROLS
2-25
COMBINATION AND PROCEDURE FOR OPERATING AIR CONDITIONING SWITCHES AND CONTROLS
Sw
Operation
fan sw
power-on
sw
Discharge
opening select
sw
temp.sw
ventil. control
sw
cooling
rapid HI ON left
normal LO - HI ON desired setting desired setting
dehumid./ventil./
pressure
LO - HI ON desired setting desired setting
heating
rapid HI OFF right
normal LO - HI OFF desired setting desired setting
defroster HI OFF or ON desired setting
NOTE
•
Warm up the engine sufciently prior to operating the fan switch.
•
It is good practice to ventilate the driver’s room if its temperature is high before cooling.
•
You will get better cooling and heating effect with the ventilation control in the indoor air circulation position. It is however recommended to ventilate the driver’s room
sometimes if air conditioning is used for a prolonged time.
FAN SWITCH
MODE SWITCH
AIR CONDITIONER
POWER SWITCH
VENTILATION
CONTROL SWITCH
TEMPERATURE
CONTROL SWITCH
•
• •
•
•
