INSTRUMENTS AND CONTROLSINSTRUMENTS AND CONTROLS
2-72-7
P (POWER) MODE INDICATORP (POWER) MODE INDICATOR
Use this mode when you need to carry loads a longUse this mode when you need to carry loads a long
distance at a high speed.distance at a high speed.
E (ECONOMY) MODE INDICATORE (ECONOMY) MODE INDICATOR
Use the E mode when your task takes a long time toUse the E mode when your task takes a long time to
nish. The truck can work a long time on a single batterynish. The truck can work a long time on a single battery
charge in this mode. The E mode is suitable for handlingcharge in this mode. The E mode is suitable for handling
loads carefully or carrying loads carefully or carrying a fragile load a fragile load slowlyslowly..
PARKING BRAKE INDICATING LIGHTPARKING BRAKE INDICATING LIGHT
Light comes on when the parking brake is applied.Light comes on when the parking brake is applied.
The truck won’t move when this light is ON.The truck won’t move when this light is ON.
NEUTRAL NEUTRAL STASTATUS TUS INDICATORINDICATOR
Light comes on when the key switch is turned to "ON"Light comes on when the key switch is turned to "ON"
and goes out when the direction shift switch is placed inand goes out when the direction shift switch is placed in
the forward or reverse position.the forward or reverse position.
NEUTRAL SAFETY INDICATORNEUTRAL SAFETY INDICATOR
If light blinks when the key switch is turned to "ON", itIf light blinks when the key switch is turned to "ON", it
indicates that the accelerator pedal or brake pedal is notindicates that the accelerator pedal or brake pedal is not
in the “up” position or any of the load handling leversin the “up” position or any of the load handling levers
is not in the neutral position. Place the acceleratoris not in the neutral position. Place the accelerator
pedal and brake pedal in the “up” position and the loadpedal and brake pedal in the “up” position and the load
handling levers in neutral.handling levers in neutral.
DRIVE-WHEEL ANGLE INDICATORDRIVE-WHEEL ANGLE INDICATOR
The indicator shows the direction of the drive wheel.The indicator shows the direction of the drive wheel.
Forward travelForward travel: : Black arrow Black arrow on the won the white backgroundhite background
Reverse travelReverse travel
: : White arrow White arrow on the on the black backgroundblack background
Neutral: Neutral: Black Black bar bar on on the the white white backgroundbackground
