INSTRUMENTS AND CONTROLSINSTRUMENTS AND CONTROLS
2-82-8
INTERLOCK WARNING LIGHTINTERLOCK WARNING LIGHT
Light comes on when the operator is not in theLight comes on when the operator is not in the
operator's seat. With the interlock warning light ON, theoperator's seat. With the interlock warning light ON, the
truck won’t travel and the load handling system won’ttruck won’t travel and the load handling system won’t
operate.operate.
If the key switch is turned to the “ON” position with noIf the key switch is turned to the “ON” position with no
operator present in the operator’s seat, the neutraloperator present in the operator’s seat, the neutral
safety indicating light blinks and the interlock warningsafety indicating light blinks and the interlock warning
light comes on. The truck won’t travel. When thelight comes on. The truck won’t travel. When the
interlock system is activated, number 105 or 106 isinterlock system is activated, number 105 or 106 is
shown on the screen. For the procedure for releasingshown on the screen. For the procedure for releasing
the interlock system, see page 2-24.the interlock system, see page 2-24.
LOAD METERLOAD METER
The load meter indicates the weight of the load beingThe load meter indicates the weight of the load being
carried on the forks. The measurement of the loadcarried on the forks. The measurement of the load
weight [1] starts 3 seconds after both the travel and loadweight [1] starts 3 seconds after both the travel and load
handling systems are stopped, and is repeated afterhandling systems are stopped, and is repeated after
that every 0.5 seconds for 4 seconds. The load meterthat every 0.5 seconds for 4 seconds. The load meter
keeps showing the most recently measured value until akeeps showing the most recently measured value until a
new measurement is obtained.new measurement is obtained.
If the “+” button [2] on the keypad is pressed and heldIf the “+” button [2] on the keypad is pressed and held
down while the instrument panel is showing the maindown while the instrument panel is showing the main
screen, the truck is stationary, and the load handlingscreen, the truck is stationary, and the load handling
levers are in neutral, the load meter will be reset levers are in neutral, the load meter will be reset to zero.to zero.
If the load weight is a minus value, the load meter willIf the load weight is a minus value, the load meter will
read zero.read zero.
NOTENOTE
The load weight [1] shown on the screen should onlyThe load weight [1] shown on the screen should only
be used as a guide. It is not necessarily accuratebe used as a guide. It is not necessarily accurate
because it is calculated using the hydraulic pressurebecause it is calculated using the hydraulic pressure
applied to the lift cylinders.applied to the lift cylinders.
1. Measurement1. Measurement
2. 2. + + buttonbutton
