Technical Data
PG-E-Series | Version 2.15 9
4.2 Type plate
Fig. 2: Type plate Generator PG-E 100 TEA H
Model PG-E 90 SEA
Voltage 230 V
Limited output power
(apparent power)
8,8 kVA
Limited output power
(active power)
8 kW
Continuous output power
(apparent power)
8,25 kVA
Continuous output power
(active power)
7,5 kW 2
Power factor 0,9 Cos ɸ
Voltage deviation max. +/- 3%
Drive motor power max. 11,7 kW
Motor speed 3600 rpm
Fuel Petrol
Starter Manual start /
Electric starter
Running time at 50% load 12 hours
Running time at
100% load
8 hours
Tank capacity 25 Liter
Consumption at 75% load 2,5 l/h
Sound pressure level 67 dB(A)
Weighted sound power
level (L
WA
)
97 dB(A)
Socket type 2x 230V shockproof /
1x 230V CEE 32A
Generator IP degree of
protection
IP 23 M
Socket IP degree of
protection
IP 44
Dimensions (LxWxH) 700 x 526 x 580 mm
Weight 93,7 kg
Motor oil volume
min./max.
0,6 - 1,2 Liter
Model PG-E 100 TEA H
Voltage 230V/400 V
Limited output power
(apparent power)
4,05 / 13,2 kVA
230V/400V
Limited output power
(active power)
3,68 / 11 kW
230V/400V
Continuous output power
(apparent power)
3,79 / 12 kVA
230V/400V
Continuous output power
(active power)
3,45 / 10 kW
230V/400V
Power factor 0,9 / 0,8 Cos ɸ
Fuel Petrol
Starter E-Start
Runtime at 50% load 10 hours
Runtime at 100% load 8 hours
Tank capacity 45 Liter
Consumption at 75% load 6 l/h
Speed 3000 min
-1
Sound pressure 79 dB(A)
Sound power level LWA 99 dB(A)
Sockets version 2 x 230 V / 1×400V
Protection class Genera-
tor
IP 23
Protection class sockets IP 44
Power max. drive motor 14 kW
Power Drive motor 14,0 kW
Dimensions generator
(LxWxH)
730x600x910 mm
Weight 170 kg
Engine oil quantity
min./max.
1,3 Liter
Model PG-E 100 TEA H
