4
Controls and Functions
1. LCD Display Displays time, channel, frequency, and functions. (Page 6)
2. Numeric Keys Press to program a frequency into each channel for scanning.
Also, press for time entries and direct channel access with MANUAL key.
And press for channel presets in Radio Mode
3. Decimal Key Press to enter the decimal point in the frequency. Also, use for
clearing mistakes during entries by pressing twice.
4. E Key Enters the frequency or time setting into memory.
5. VOLUME Turn clockwise to increase the volume. Turn counterclockwise to
decrease the volume.
6. SQUELCH Adjusts the squelch threshold, or use AUTO for the factory setting.
7. OFF Key Turns scanner and radio off and Clock Mode on.
8. SCANNER Key Selects the Scanner Mode .
9.
RADIO AM/FM Key
Selects the Radio Mode. Also selects AM/FM in Radio Mode.
