Connecting the Microphone
10
UNIDEN UH9060/UH9080 UHF CB Transceiver
MIC Jack
%HIRUHFRQQHFWLQJWKH0LFURSKRQH-DFNGHFLGHLI\RXQHHGWRXVHWKHPHWUH
Extension Cable - simply connect the MIC plug into the jack end of the Extension
Cable
Push the MIC plug or Extension Cable plug into the MIC jack of the radio until the
connection locks into place. Gently tug the MIC or Extension Cable cord to test that the
connection is locked. Use the rubber cover which is on the cord to seal the MIC jack
entry from dust.
Disconnecting the MIC from the MIC Jack
3XOOEDFNWKHUXEEHUFRYHUDQGPRYHLWGRZQDORQJWKHFRUG8VLQJWKHÀDWEODGHRID
screwdriver or similar object carefully push the lock tab of the MIC plug towards the
MIC cord and at the same time tug on the MIC cord to draw back the MIC plug.
0LF-DFNIRU
Remote LCD
Speaker Mic
Spare (covered)
for optional
0LF-DFN
