2.

Terminal/Server

Authentication is made by the terminal, even if the server is connected,

and authentication result transferred to the server on a real-time basis.

3. Server Only

However, authentication is made by the server when the input user ID or

card is not registered in the terminal (it doesn’t attempt server

authentication in case of 1:N fingerprint authentication).

4.

Terminal Only

Although the user is registered in the terminal, authentication is made via

the server. Therefore, authentication cannot be performed unless the

server is connected.

Flexible designation is allowed depending on the circumstance, such as the number of

terminals connected to the server, the number of users authenticated, or network errors

etc. It is recommended to use ‘2. Terminal/Server’ so concurrent authentications can be

attempted if 10> terminals are connected to the server, or if frequent network errors

occur.

※ In the server authentication mode, logs are stored in the server, not the terminal.

3.5. Application

Selecting ‘3. Application’ in the main menu causes the following screen to appear:

Press the applicable key representing the item to be

changed.

3.5.1. Application

Select ◆ [ENT~]  [3. Application]  [1. Application] in the initial screen ◆, and the

following screen appears:

Select the terminal operation type by pressing the

applicable numeric key.

Press the [ENT] key to apply the configuration and

[F4 (←)] key to cancel it.
