AC-5000 / 5100 User Guide 45
UNIONCOMMUNITY Co., Ltd. / 12F, Daemyung Valeon, 127, Beobwon-ro,
Songpa-gu, Seoul, 05836, Republic of Korea
TEL: +82-2-6488-3000 / FAX: +82-2-6488-3100 E-Mail :sales@unioncomm.co.kr
http://www.unioncomm.co.kr
3.6.2. Authentication
Select ◆ [ENT~] ([4. System] [2. Authentication]) in the initial screen ◆, and the
following screen appears:
▶ User Group ID
The method of authentication where the initial digit of an ID relates to a group. It
completes 1:N authentication faster when more than 5,000 users are registered.
When this method is checked, it authenticates the fingerprint from users whose ID
starts with the same input letter. If this method is not checked, it considers the input
figure as the user ID and attempts 1:1 authentication against the fingerprint of the
user with the applicable ID
Example: Where the user inputs ‘12’ to attempt authentication when the user ID is a 4-
digit figure;
If checked (
),1:N authentication is attempted from users having ID
‘1200’~’1299’,
If unchecked ( ),1:1 authentication is attempted from fingerprints of users
whose ID is ‘12’.
▶ Enable 1:N
If checked ( ), this option enables fingerprint only authentication without inputting
user ID or card. Even if the user is registered with 1:N authentication, only 1:1
authentication is permitted in the terminal where this option is not checked.
▶ Card Only
If checked ( ), this option enables card only authentication without inputting
fingerprint. Even if the user is registered with (Card & FP) or (Card & PW), only
authentication with card is permitted in the terminal where this option is checked.
▶ Template On Card
If checked ( ), this option enables authentication with the user’s information and
fingerprint recorded in the card without downloading the user in the terminal. In order
for this option to be operated, SC card reader must be mounted and the server must
set which terminal uses that fingerprint card.
To Next Page
