9
2-4-3
Uninstallation of cable
Figure 2-5
Remove the interface cable:
1. Find the release-hole.
2. Insert a thin wire into the hole and pull out the cable gently.
2-5 Assembling the stand
Note: The stand is an optional accessory.
1. See the figure above, tighten the screws.
2. Bend the neck to the desired position for scanning.
3. Screw mounting: Screw one #10 wood screw into each screw-mount-hole until the base of the stand
is secured.
4. Tape mounting: Peel the paper liner off one side of each piece of tape and place the sticky surface
over each of the three rectangular tape holders. Peel the paper liner off the exposed sides of each
piece of tape and press the stand on a flat surface until it is secure.
