Prefix transmission: By setting Enable, prefix will be appended before the data transmitted.
Suffix transmission: By setting Enable, suffix will be appended after the data is transmitted.
Code name transmission: By setting Enable, code name will be transmitted before code data.
Preamble transmission: By setting Enable, preamble will be appended before the data
transmitted.
Postamble transmission: By setting Enable, postamble will be appended after the data is
transmitted.
Code ID transmission: Code ID can be transmitted in the format of either Proprietary ID or AIM
ID. Refer to 1-2 Default setting for each barcode.
Code length transmission: The length of code data string can be transmitted before the code
data when Enable is selected. The length is represented by a number with two digits.
Case conversion: The characters within code data or the whole output string can be set in either
upper case or lower case.
FN1 substitution transmission: The scanner supports a FN1 substitution feature for USB and
RS-232 interface. The replacement string of FN1 can be chosen by user (see 3-38 G1-G6 & C1-C3
& FN1 substitution string setting).
All-non-printable-character string transmission with string setting: By setting enable, all
string settings, e.g. Preamble transmission or Insert G1 string setting, are active for an all-non-
printable-character string. Here a non-printable character means a character with ASCII value
between 0x00 to 0x1F.
Transmit the first N data characters only: The scanner supports to only transmit the first N data
characters of a barcode. The number of N can be set as a digit between 1 and 99.
Transmit the last N data characters only: The scanner supports to only transmit the last N data
characters of a barcode. The number of N can be set as a digit between 1 and 99.
