72
Multiple-scan setting
Single-scan setting
Option barcode
Option
Alpha.
entry
R
ead
Disable
00
Enable
01*
*
Check digit verification
Disable
00
Enable
01*
*
Check digit transmission
Disable
00*
*
Enable
01
Max. code length
00
-
99
00
-
99
00*
*
Min. code length
00
-
99
00
-
99
01*
*
Code ID setting
00
-
FF
16
00
-
FF
16
<P>*
*
Insertion group selection
00
-
44
00
-
44
00
*
*
Encode character set type
Alphanumeric
00*
*
Numeric
01
76
78
