84
Example:
Replace all the “A” character in a data string with “B” character.
Original code
data
“1 2 3 A 5 A”
Output code data
“1 2 3 B 5 B”
Steps: scan the following barcodes in order. The ASCII value for “A” is 41, and the ASCII value for
“B” is 42.
Testing barcode:
Multiple characters C3 replacement: By setting, a number of defined characters in the data
string can be replaced by other defined characters. The maximum number of characters to replace
is 11.
Example: Replace all the “A” character in a data string with “B” character; replace “C” with “D”;
replace “E” with “F”.
Original code
data
“1 2 3 A 4 C 5 6 E 7 8”
Output code data
“1 2 3 B 4 D 5 6 F 7 8”
Steps: scan the following barcodes in order. The ASCII value for “A” is 41, for “B” is 42, for “C” is
43, for “D” is “44”, for “E” is 45, and for “F” is 46.
