91
Multiple-scan setting
Single-scan setting
Option barcode
Option
Alpha.
entry
Lower (whole string)
04
FN1 substitution transmission
Disable
00*
*
USB
01
RS
-
232
02
USB/RS-
232
03
All-non-printable-character string
transmission with string setting
Disable
00*
*
Enable
01
Transmit the first N data
characters only
All
99*
*
01
-
99
Transmit the last N data
characters only
All
99*
*
01
-
99
95
97
