MS652 User’s Manual
3.2.12 UPC/EAN/JAN Supplemental AIM ID
Format
If Transmit Code ID Character is set to AIM Code ID Character, scan one of
the following bar codes to select an output format when reporting
UPC/EAN/JAN bar codes with supplementals:
• Separate - Transmit UPC/EAN/JAN with supplementals with separate AIM IDs but
one transmission, i.e.,]E<0 or 4><data>]E<1 or 2>[supplemental data]
• Combined – Transmit UPC/EAN/JAN with supplementals with one AIM ID
and one transmission, i.e.,]E3<data+supplemental data>
• Separate Transmissions - Transmit UPC/EAN/JAN with supplementals with
separate AIM IDs and separate transmissions, i.e.,
]E<0 or 4><data>
]E<1 or 2>[supplemental data]
Separate
Combined*
Separate Transmissions
