OX Amp Top Box Controls & Connectors 14
RIG LED (2)
The LED beneath the RIG knob illuminates to indicate certain operating conditions. The
LED states encountered during normal operation are listed in the table below.
Note: If RIG LED states not listed below are encountered, please contact UA
Technical Support.
RIG LED State Indication Notes
Off OX not powered
Rear panel POWER switch is in down position and/
or AC adapter is not properly connected
Green (solid) RIG not modified
Active RIG has been loaded via RIG knob or OX app
and is unchanged from stored version
Amber (solid) RIG modified
Active RIG has been edited via ROOM knob or OX
app and is not stored
Amber (blinking) Firmware update Firmware update is in process
Green (blinking)
Wi-Fi reset initiated and
awaiting user confirmation
Press reset switch again within 10 seconds to
confirm Wi-Fi reset
Red (blinking)
Factory reset initiated and
awaiting user confirmation
Press reset switch again within 10 seconds to
confirm factory reset
ROOM (3)
The ROOM knob adjusts the amount of mic’d studio ambience and air. Increase this
knob for more room ambience, or decrease for a drier close-mic tone.
When ROOM is adjusted, the RIG LED illuminates in amber, indicating the ROOM
amount is different than the value stored in the active RIG preset.
ROOM sounds are heard in the LINE / MON, HEADPHONE, and S/PDIF outputs, but not
in the TO SPEAKER output.
Tip: ROOM settings can be edited and stored with the OX software app.
