Universal Audio OX User Manual

OX Amp Top Box Specifications 55
Specifications
Note: All OX Amp Top Box specifications are subject to change without notice.
SYSTEM
I/O Complement
Amplifier Input One
Speaker Output One
Line Outputs Two (one stereo left/right)
Headphone Output One (stereo left/right)
Digital Outputs Two (mirrored)
ANALOG I/O
Amplifier Input
Connector Type ¼” Female TS Unbalanced
Input Impedance 4/8/16 Ohms (selectable)
Maximum Input Power 150 Watts RMS, 200 Watts RMS peak
Safety Load (power off) 16 Ohms
Speaker Output
Connector Type ¼” Female TS Unbalanced
Output Attenuation Five Attenuation Steps and Speaker Off
Output Latency None (pure analog)
Line Outputs 1 – 2
Connector Type ¼” Female TRS Balanced
Dynamic Range 114.5 dB (A-weighted)
Frequency Response 20 Hz – 20 kHz, ±0.1 dB
Signal-to-Noise Ratio 114.0 dB (A-weighted)
Total Harmonic Distortion + Noise -110 dB @ -3 dBFS
Channel Separation 129 dB
Output Impedance 100 Ohms
Maximum Output Level 20.2 dBu (balanced)
Output Latency 2.77 milliseconds (122 samples @ 44.1 kHz)
Stereo Headphone Outputs
Connector Type ¼” Female TRS Stereo
Dynamic Range 113.0 dB (A-weighted)
Frequency Response 20 Hz – 20 kHz, ±0.1 dB
Signal-to-Noise Ratio 113.0 dB (A-weighted)
Total Harmonic Distortion + Noise -107 dB @ -3 dBFS
Maximum Output Power 80 milliwatts into 600 Ohms
Output Latency 2.77 milliseconds (122 samples @ 44.1 kHz)
(continued)

Universal Audio OX Specifications

General

Speaker Impedance	4, 8, 16 Ohms
Power Handling	150W RMS
Speaker Emulation	Yes
Microphone Emulation	Yes
Room Emulation	Yes
USB Audio Interface	No
MIDI I/O	No
Type	Reactive Load Box
Outputs	1 x 1/4" (line out)
Analog Inputs	1 x 1/4" (speaker in)
Analog Outputs	1 x 1/4" (line out)
Digital Outputs	1 x S/PDIF
Other I/O	1 x RJ45 (Ethernet)
