Universal Audio OX User Manual

OX Amp Top Box Rig, Cabinet, & Mic Descriptions 38
Default Rig Sets
The default Rig Sets when OX is shipped from the factory are listed in the table below.
Rig Sets can be customized, renamed, and/or assigned to OX’s RIG knob in ASSIGN view
within the OX app.
RIG SET NAME RIG SET NAME
1 Studio Standards 9 Stoner Rock
2 Big 80s 10 Open Backs
3 70s Rock 11 Closed Backs
4 60s Rooms 12 Warm and Lush
5 Crystal Cleans 13 Ambient Post
6 Dirty Rhythms 14 UK Tones
7 Modulated 15 Studio DI Tricks
8 Squashed 16 Bright and Tweaky

Universal Audio OX Specifications

General

Speaker Impedance	4, 8, 16 Ohms
Power Handling	150W RMS
Speaker Emulation	Yes
Microphone Emulation	Yes
Room Emulation	Yes
USB Audio Interface	No
MIDI I/O	No
Type	Reactive Load Box
Outputs	1 x 1/4" (line out)
Analog Inputs	1 x 1/4" (speaker in)
Analog Outputs	1 x 1/4" (line out)
Digital Outputs	1 x S/PDIF
Other I/O	1 x RJ45 (Ethernet)
