OX Amp Top Box Specifications 56
DIGITAL OUTPUTS
Format S/PDIF IEC958
Connector Type 1 Female Phono (RCA)
Connector Type 2 Optical TOSLINK JIS F05
Sample Rate & Bit Depth 44.1 kHz, 24-bit
Output Latency 2.57 milliseconds (113 samples @ 44.1 kHz)
ELECTRICAL
Power Supply External AC to DC Power Supply, Level VI compliant
AC Input Connector Type IEC Male
AC Requirements 100V – 240V AC, 50 – 60 Hz
DC Connector Type XLR 4-Pin Locking Male (Neutrik P/N NC4MDM3-H)
DC Requirements 12 VDC ±5%, 1.5A
Maximum Power Consumption 18 Watts
Operating Temperature Range 32° to 104° Fahrenheit (0° to 40° Celsius)
Storage Temperature Range –40° to 176° Fahrenheit (–40° to 80° Celsius)
Operating Humidity Range 10% – 95%, non-condensing
COMPLIANCE
EMC and Safety Standards
FCC Part 15 for Class B digital device EN 610003-3-3:2013 EN 301489-17
ICES-003 EN 55103-2 KN 301489-1
VCCI-CISPR 32:2016 KN32 KN 301489-17
EN 55032 KN35 UL/cUL 60065
CIPSR 32:2012 CNS 13438 EN 60065
EN 61000-3-2:2014 EN 301489-1 IEC 60065
PHYSICAL
Dimensions
Width 15.01 in / 381.25 mm
Height, Chassis Only 4.45 in / 112.94 mm
Height, Including Rubber Feet 5.45 in / 138.44 mm
Depth, Chassis Only 8.05 in / 204.5 mm
Depth, Including Knob & Jack Protrusions 9.04 in / 229.58 mm
Shipping Box (Width x Depth x Height)
20 3/4” x 12 15/16” x 11 5/16”
(52.7 cm x 32.9 cm x 28.7 cm)
Weight
Weight (unit only) 14.1 Lbs / 6.40 Kg
Package Contents
OX Amp Top Box Unit
External Power Supply
IEC Power Cable — US, EU, or UK (region dependent)
Quick Start Guide
RIG Control Presets
Safety & License Sheet
