Universal Audio OX User Manual

OX Amp Top Box Rig, Cabinet, & Mic Descriptions 43
CON 67
The condenser “67” can be heard on the biggest pop and rock records of the ’60s, ’70s,
and ‘80s. This tube condenser mic has a wide frequency range without sounding harsh
or bottom heavy. It has a gentle upper midrange that’s great for distorted rhythm guitars.
DIRECT
In direct mode you get the raw sound of your amp, without a guitar speaker, while still
responding as if the amp is driving a proper reactive speaker load.

Universal Audio OX Specifications

General

Speaker Impedance	4, 8, 16 Ohms
Power Handling	150W RMS
Speaker Emulation	Yes
Microphone Emulation	Yes
Room Emulation	Yes
USB Audio Interface	No
MIDI I/O	No
Type	Reactive Load Box
Outputs	1 x 1/4" (line out)
Analog Inputs	1 x 1/4" (speaker in)
Analog Outputs	1 x 1/4" (line out)
Digital Outputs	1 x S/PDIF
Other I/O	1 x RJ45 (Ethernet)
