1. Filter;
Select what filter to activate
Info filter:
Warning filter:
Error filter:
2. Tool bar;
Load log files, export error codes, change language
3. Text search;
Type error code or text
4. Log start Info bar*;
Created every time the robot is powered on.
5. Highlighted text;
When tapped, gives more detailed Information.
6. PolyScope time
7. Reporter;
Where the info is reported from ”safety, PolyScope, etc.”
8. Message;
Text with the Cxxxx refers to the error codes.
9. Log Entries;
Shown and total
10. Expand or collapse all Info bars (point 4)
NOTICE
After loading the log file every Log Start Info Bar (4) is collapsed and only the
summary for each log start is visible.
e-Series 92 Service Manual
6.Troubleshooting
