Color Codes
Gray
Plane is configured but disabled (A)
Yellow & Black
Normal Plane (B)
Blue & Green
Trigger Plane (C)
Black Arrow
The side of the plane the tool and/or elbow is allowed to be on (For Normal Planes)
Green Arrow
The side of the plane the tool and/or elbow is allowed to be on (For Trigger Planes)
Gray Arrow
The side of the plane the tool and/or elbow is allowed to be on (For Disabled
Planes)
UR10e 156 User Manual
Copyright © 2009–2024 by UniversalRobotsA/S. All rights reserved.
