BASE INSTALLATION WITH VEHICLE SEAT BELT
We recommend using the load leg to optimize safety of the child in the seat. Load leg should be placed in stowed
position when not in use. If installing without the load leg, bypass step 1 and proceed to step 2.
LEVELING BASE
1 Press the load leg release button on bottom of the base and pull load leg
out from storage. Place on the vehicle seat with the load leg extended toward
the front of the vehicle cushion.
NOTE: We recommend removing the vehicle floor mat before installation.
2 Lift the level adjust handle on the top of the base to extend the foot and
change the recline angle. Check the bubble level angle indicator on either
side of the base. The base is level when the bubble is fully between the lines.
NO partial bubble allowed.
NOTE: If the bubble is not visible, lower the foot to the lowest position and
complete installation. Upon completion, the bubble should fall between the
two lines.
NOTE: Vehicle must be parked on a level surface to properly level the base.
3 Open the lock-o door by lifting the top then the bottom portions to access
the belt path.
If proper angle cannot be
achieved with level adjustable
foot, a rolled towel may be
used. Foot must be in fully
extended position.
Proceed to chosen installation method:
LAP/SHOULDER ROUTING METHOD PAGE 34
LAP BELT ONLY ROUTING METHOD PAGE 36
