GENERAL USE – Securing Your Child
4 Pull up on the harness to remove excess slack around the child’s legs.
5 Pull the harness adjuster strap to snugly adjust the harness straps around
your child.
6 Close retainer clip and position at armpit level. Make sure the shoulder
pads don’t interfere with positioning the chest clip.
HARNESS SHOULD BE SNUG.
Pinch harness webbing at child’s
shoulders.If you can pinch webbing,
the harness is too loose and should
be tightened.
GENERAL USE – Attaching Carrier to Base
1 Place carrier on base until a click is heard.
2 Check for a secure connection by pulling up on carry handle.
Carry handle must be locked in the (4th)
rebound position whenin use in the vehicle.
1
2
4 5
6
