CARRIER INSTALLATION WITH VEHICLE SEAT BELT
Lap/Shoulder Optional Routing Method
1 Route the lap portion of the seat
belt through both lap belt guides
on the carrier, and buckle the seat
belt.
2 Lock vehicle seat belt.
3 Push the carrier into the vehicle
seat bight (crease of the seat) and
gently apply pressure from behind
the carrier into the vehicle seat
back. At the same time, pull on the
shoulder portion of the vehicle
belt closet to the buckle and hold
tightly.
NOTE: Be mindful of canopy.
4 Feed excess webbing into the vehicle
retractor.
5 Rotate carry handle forward to the
(4th) rebound position when in use.
NOTE: Check that the carrier is still
properly leveled.
REVIEW SAFETY CHECK
ON PAGE 51.
All steps must be achieved.
CARRIER INSTALLATION WITH VEHICLE SEAT BELT
Lap/Shoulder Optional Routing Method
4 51
3
2
