Page 14 104044-001 AB62 Work Platform - Operator Manual
Daily Maintenance
D AILY M AINTENANCE
F UELING
Stop the engine and turn off the key switch before re-fueling.
Figure 9:
Fuel Tank
G ASOLINE
1. Open the left turret cover, then open the fill cap.
2. Fill to capacity with unleaded gasoline only.
• Fuel tank full capacity is 159 liters (
42 US gallons
).
3. Install the cap.
D IESEL
1. Open the left turret cover, then open the fill cap.
2. Fill to capacity with diesel motor fuel only, grade #1-D or #2-D.
Use distillate fuel only; do not use residual or blend.
• Fuel tank full capacity is 159 liters
(42 US gallons
).
3. Install the cap.
LPG ( OPTION )
1. Unfasten the coupler from the LPG valve on the tanks.
2. Remove the LPG tanks from the machine and fill according to ASME, NFPA and local standards.
IMPORTANT: When using propane, use clean, water free liquid petroleum gas, preferably from a bulk storage tank.
WARNING
!
!
If you smell propane, close the supply valve on both tanks immediately until you have located and
corrected the leak.
H YDRAULIC F LUID
Figure 10:
Hydraulic Fluid Tank
1. Open the turret cover and check the fluid level at the sight
gauge with the boom stowed and retracted; engine running or
stopped.
NOTE:
Never add hydraulic fluid if the boom is elevated or extended.
2. If necessary, fill to capacity with clean ISO compatible hydraulic
fluid.
• Normal Temperature, above 0° C (
32° F
)__ ISO #46.
• Low Temperature, below 0° C (
32° F
) ____ ISO #32.
• Extreme Temperature, below -17° C (
0° F
) ISO #15.
3. Clean the area around the cap before opening.
4. Open the filler/breather cap to add hydraulic fluid.
5. Install the cap.
Fuel Cap
Hydraulic Fluid Filler Cap
Level Gauge
