Page 12 114110-000 X-Series - Operator Manual
Transporting the Machine
D
RIVING
OR
W
INCHING
ONTO
A
T
RUCK
OR
T
RAILER
Never winch faster than 0,3 m/sec. (
1 ft./sec.
).
Never operate the machine with the parking brakes released. Serious injury or damage could result.
1. Loading the machine onto the truck or trailer;
A. To
Drive
the machine onto the transport vehicle:
a. Turn the Lift/Drive Switch to DRIVE LOW (hi-torque mode) and drive the machine up the ramp and
into transport position.
b. Set the wheels straight and turn off the machine.
c. Chock the wheels.
B. To
Winch
the machine onto the transport vehicle:
a. Drive the machine up to the ramp.
b. Attach the winch cable to the tie down/lifting points.
c. Release the parking brakes (refer to “Parking Brake Release” on page 10).
d. Winch the machine into transport position
e. Chock the wheels.
f. Re-engage the parking brakes.
2. Secure the machine to the transport vehicle with chains or straps of adequate load capacity attached to
the chassis tie down/lifting points (refer to Figure 8).
Overtightening chains or straps attached to the Tie Down points may result in damage to the machine
