Upright X20W - Technical Specifications

Page 20 114110-000 X-Series - Operator Manual
Specifications
S PECIFICATIONS
Specifications are subject to change without notice. Hot weather or heavy use may affect performance.
Refer to the Service Manual for complete parts and service information.
ITEM X20N X20W X26N X26UN X31N
Platform Size
Platform Extension In
0,71 m x 2,21 m
[28 in. x 87 in.]
1,17 m x 2,21 m
[46.25 in. x 87 in.]
1,17 m x 2,21 m
[46.25 in. x 87 in.]
0,71 m x 2,21 m
[28 in. x 87 in.]
1,17 m x 2,21 m
[46.25 in. x 87 in.]
Platform Extension Out
0,71 m x 3,2 m
[28 in. x 126 in.]
1,17 m x 3,2 m
[46.25 in. x 126 in.]
1,17 m x 3,2 m
[46.25 in. x 126 in.]
0,71 m x 3,2 m
[28 in. x 126 in.]
1,17 m x 3,2 m
[46.25 in. x 126 in.]
Max. Platform Capacity
Standard
340 kg [750 lbs.] 455 kg [1000 lbs.] 455 kg [1000 lbs.] 227 kg [500 lbs.] 318 kg [700 lbs.]
on Extension
110 kg [250 lbs.] 110 kg [250 lbs.] 110 kg [250 lbs.] 110 kg [250 lbs.] 110 kg [250 lbs.]
Max. No. of occupants
Standard (total)
2 people 4 people 3 people 2 people 3 people
on Extension
1 person 1 person 1 person 1 person 1 person
Height
Working Height
7,9 m [26 ft.] 7,9 m [26 ft.] 9,8 m [32 ft.] 9,7 m [31 ft. 10 in.]11 m [36 ft.]
Max. Platform Height
6,1 m [20 ft.] 6,1 m [20 ft.] 7,9 m [26 ft.] 7,87 m [25 ft. 10 in.] 9,4 m [30 ft. 7 in.]
Min. Platform Height
0,96 m [38 in.] 0,96 m [38 in.] 1,09 m [43 in.] 1,09 m [43 in.] 1,22 m [48 in.]
Dimensions
Weight
1736 kg [3828 lbs.] 1938 kg [4273 lbs.] 2153 kg [4747 lbs.] 2358,7 kg [5200 lbs.] 2486 kg [5480 lbs.]
Overall Width
0,82 m [32.5 in.] 1,22 m [48 in.] 1,22 m [48 in.] 0,82 m [32.5 in.] 1,22 m [48 in.]
Overall Height
2,06 m [78.5 in.] 2,06 m [78.5 in.] 2,19 m [83.5 in.] 2,19 m [86 in.] 2,25 m [88.5 in.]
Overall Height, Rails Lowered
N/A N/A N/A 1,99 m [78.25 in.] 1,88 m [74 in.]
Overall Length, Extension In
2,35 m [92.5 in.] 2,35 m [92.5 in.] 2,35 m [92.5 in.] 2,35 m [92.5 in.] 2,35 m [92.5 in.]
Overall Length, Extension Out
3,26 m [128.5 in.] 3,26 m [128.5 in.] 3,26 m [128.5 in.] 3,26 m [128.5 in.] 3,26 m [128.5 in.]
Drivable Height 6,1 m [20 ft.] 6,1 m [20 ft.] 7,9 m [26 ft.] 7,87 m [25 ft. 10 in.] 9,4 m [30 ft. 7 in.]
Drive Speed
Platform Lowered
0 to 3,2 km/h
[0 to 2.0 mph]
0 to 3,2 km/h
[0 to 2.0 mph]
0 to 3,2 km/h
[0 to 2.0 mph]
0 to 3,2 km/h
[0 to 2.0 mph]
0 to 3,2 km/h
[0 to 2.0 mph]
Platform Raised
0 to 1,0 km/h
[0 to 0.62 mph]
0 to 1,0 km/h
[0 to 0.62 mph]
0 to 1,0 km/h
[0 to 0.62 mph]
0 to 0,8 km/h
[0 to 0.50 mph]
0 to 1,0 km/h
[0 to 0.62 mph]
Energy Source 24 Volt Battery Pack (4-235 A Hour, 6 Volt Batteries, min. wt. 30 kg [66 lbs.] each)
Motor 24 Volt 4 Horse Power DC Electric Motor
System Voltage 24 Volt DC
Battery Charger 25 A, 110/220 VAC
Hydraulic Reservoir Capacity 15 L [4 US Gallons]15 L [4 US Gallons] 15 L [4 US Gallons]15 L [4 US Gallons] 18,9 L [5 US Gallons]
Maximum Hydraulic Pressure 207 bar [3000 psi]
Hydraulic Fluid
Normal Temperature (0° C [>32° F])
ISO #32
Low Temperature (0° C [<32° F])
ISO #32
Extreme Temperature (-17° C [<0° F])
ISO #15
Lift System
One Single Stage
Lift Cylinder
One Single Stage
Lift Cylinder
One Single Stage
Lift Cylinder
One Single Stage
Lift Cylinder
Two Single Stage
Lift Cylinders
Lift Speed
Lift, 30 sec.
Lower 30 sec.
Lift, 40 sec.
Lower 30 sec.
Lift, 45 sec.
Lower 40 sec.
Lift, 42 sec.
Lower 40 sec.
Lift, 65 sec.
Lower 40 sec.
Control System Proportional Control Handle with Interlock Switch, Rotary Lift/Drive Switch, and Red Mushroom Emergency Stop Switch
Drive System Dual Front Wheel Hydraulic Motors
Tires 381 mm [15 in.] Diameter Solid Rubber, non-marking
Parking Brake Dual Spring Applied, Hydraulic Release
Turning Radius 203 mm [8 in.] Inside
Maximum Gradeability 14° [25%] 15,5° [28%]15° [27%]14.5° [26%]14° [25%]
Wheel Base 1,9 m [74.75 in.]
Guardrails 1,1 m [43.25 in.] High
Toe Boards 15,2 cm [6 in.]
Ground Clearance 89 mm [3.5 in.]
