US Cutter Copam - Replacing a Worn Blade

- 17 -
Replacing a Worn Blade
First remove the blade carriage from the carriage arm,
Unscrew the cap of
the blade carriage
Carefully pinch the
blade on both sides
and pull it up and out
of the Blade
Carriage.
Follow the steps from “Installing a New Blade” on the previous page.
Loosen the locking knob on the
carriage arm.
Place Blade carriage into the
carriage arm.
Tighten the locking knob on the
carriage arm.
