US Cutter Copam - Back View of Pinch Rollers; Pinch Roller Tension Adjustment

- 6 -
Back View
Pinch Rollers
Holds the media tightly to the feed roller below. Back view shown in detail below.
Detail of Pinch Roller (Back View)
Tension Screw
Adjusts the tension of how tightly
the pinch roller is held to the feed
roller below.
Release Lever
Allows you to release Pinch Rollers
(either so they can be moved from side
to side or to allow media to be easily fed
below them) by pulling up on the
Release Levers.
