3.4.2.
3.4.2.
3.4.2.
3.4.2. Power
Power
Power
Power
This system has three power supply interface, a power hub, a 5.08 terminal.
Power supply socket, outer diameter 5.5 mm inner 2.1 mm standard size, inside plus, outside
minus. The input voltage range 5 ~ 1 8
V,
current 150 MA. We default supply high quality 5 V / 1
A power adapter.
3.4.3.
3.4.3.
3.4.3.
3.4.3. LED
LED
LED
LED status
status
status
status
Equipment have 4 indicator lights in total, sequence from left to right .
ID Name Description
1 Power(red) Bright after power on
2 Work(green) Flash at work
3 Link(green) In RJ45 port, bright after network connection
4 Data(yellow) In RJ45 port, flash if there are datas on network
Diagram 3 - 13 LED definition
3.4.4.
3.4.4.
3.4.4.
3.4.4. RS232
RS232
RS232
RS232 interface
interface
interface
interface
The serial port is male (needl), RS232 level (can be directly connected to computer serial),
part of RS232 pin sequences consistent to computer COM port. When connected with the
computer, we need to use cross cable (2-3 cross, 7-8 cross, 5-5 direct, 7-8 can don ’ t connect, but
musn ’ t direcly connect to computer . Otherwise, it might lead to irregularly work).
The DB9 interface contains the RS232, RS485 and RS422 interfaces.
Number RS232 Description
1 - -
2 RXD RS232 device receive data pin
3 TXD RS232 device transmit data pin
4 - -
5 GND Signal ground
6 - -
7 RTS RS232 require to send
8 CTS RS232 clear to send
9 - -
Diagram 3 - 14 DB9 interface
