Multifunctional serial to Ethernet module user manual http://en.usr.cn
Jinan USR IOT Technology Co., Ltd tec@usr.cn
Page 5 /
/
/
/ 9
1.
1.
1.
1. Introduction
Introduction
Introduction
Introduction
1.1.
1.1.
1.1.
1.1. Overview
Overview
Overview
Overview
The USR-TCP232- E45 is an intelligent plug-and-play RS232 to Ethernet adapter that
enables any device or machine with a serial port, to become Ethernet network and
Internet enabled. Go from Ethernet to serial with the USR-TCP232- E45 . It features a
powerful built-in device server, so you can access your serial device from anywhere in the
world over internet! The USR-TCP232- E45 is easily configured via Ethernet, and can
also be set up through the serial port and web pages .
We Provide Network products and the best service to our customers.
• Chips • Modules • Software • Products
1.2
1.2
1.2
1.2 Features
Features
Features
Features
1. New Cortex-M3 kernel, industrial working temperature range, elaborate optimization
TCPIP protocol stack, stable and reliable.
2. A RS232 port, can set COM port and working mode independently, work
independently, support RTS/CTS hardware flow control.
3. A RS232/RS485 compatible port, auto adaptation.
4. RS232 and RS485 can be used together, work independently, distinguish the
connected serial port via port number.
5. Auto-MDI/MIDX function, discretionarily connect cross-over or direct network cable,
automatic switching.
6. Support TCP Server, TCP Client, UDP, UDP Server, HTTPD Client various of work
modes.
7. Support virtual serial work way, provide corresponding software.
8. Serial port highest baud rate from 110bps to 102 4 0 00 bps(COM0 only max
256000bps) .
9. wide voltage input, more applications.
10. Support DHCP automatically access IP, can inquire the facility within network
through the UDP broadcast protocol.
11. Supply the protocol for VIP customers, can integrate parameter seting function to
users ’ software applications.
12. Provide PC TCP/IP SOCKET programming example, VB , C++ , Delphi , Android , IOS.
13. The built-in web page, also parameter setting via web, can customize web pages for
users.
14. Can also set via UDP, provide the set up protocol and software source code.
15. Reload button, a key restore default Settings.
