Multifunctional serial to Ethernet module user manual http://en.usr.cn
Jinan USR IOT Technology Co., Ltd tec@usr.cn
Page 27 /
/
/
/ 9
Diagram 3 - 16 USR-TCP232-500
1) Mechanical dimesion : ( L × W × H): 155 × 100 × 34 (mm) , including RJ45 and connector
2) PCB dimension (L × W): 130.5 × 90.2 (mm) ;
3) +5 ~ +48V power input
4) DC power plug, 5.08 connector power input
5) 3 * serial(2 * RS232, 1 * RS485/422)
6) 2 * RS232 support hardware flow control
7) 1 * RS485/RS422
8) Specific: PIN 9 of the RS232 DB9 can connect to power for special uses.
3.5.2.
3.5.2.
3.5.2.
3.5.2. Power
Power
Power
Power
This system has three power supply interface, a power hub, a 5.08 terminal, pin 9 of the two
serial com (through the PCB jumper short circuit, default closed).
Power supply socket, outer diameter 5.5 mm inner 2.1 mm standard size, inside plus, outside
minus. The input voltage range 5 ~ 48
V,
current 150 MA. We default supply high quality 5 V / 1
A power adapter.
Power supply socket, the terminal and pin 9 of the com , mutual unicom, can choose one
power supply in, and another power supply out, better adapt to the use environment.
3.5.3.
3.5.3.
3.5.3.
3.5.3. LED
LED
LED
LED status
status
status
status
Equipment have 4 indicator lights in total, sequence from left to right .
ID Name Description
1 Power(red) Bright after power on
2 Work(green) Flash at work
3 Link(green) In RJ45 port, bright after network connection
4 Data(yellow) In RJ45 port, flash if there are datas on network
Diagram 3 - 17 LED definition
3.5.4.
3.5.4.
3.5.4.
3.5.4. RS232
RS232
RS232
RS232 interface
interface
interface
interface
It have 2 * RS232 interface. The serial port is male (needl), RS232 level (can be directly
connected to computer serial), part of RS232 pin sequences consistent to computer COM port.
When connected with the computer, we need to use cross cable (2-3 cross, 7-8 cross, 5-5 direct,
7-8 can don ’ t connect, but musn ’ t direcly connect to computer. Otherwise, it might lead to
irregularly work).
The DB9 interface contains the RS232, RS485 and RS422 interfaces.
