head 2 Head( 55 BA/55 C1/55 C2 ) 55 BA 55 BA
Target IP 4 Target IP 192.168.0.201 C9 00 A8 C0
Target port 2 Target port 8234 2A 20
Module IP 4 Module IP 192.168.0.7 07 00 A8 C0
Module port 2 Module port 20108 8C 4E
gateway 4 Gateway IP 192.168.0.201 C9 00 A8 C0
Work mode 1
1 for TCP Client ; 0 for UDP ; 2
for UDP Server ; 3 for TCP
Server
TCP Client 01
Baud rate 3 Serial baud rate 115200 00 C2 01
serial param 1 Databit s , stopbit s, v erifybit s N,8,1 03
Unique ID 3
ID-H, ID-L, ID-type , 0 for no
use
No use 00 00 00
Subnet mask 4 Subnet mask, low front 255.255.255.0 00 FF FF FF
Sum verify 1
Sum verification, from target
ip until end
(sum itself not included)
sum B9
Total cmd ： 55 BA C9 00 A8 C0 2A 20 07 00 A8 C0 8C 4E C9 00 A8 C0 01 00 C2 01 03
00 00 00 00 FF FF FF B9
Diagram 4 - 1 protocol structure and example
Note.
1. Head definition.
55 BA for write Port0 ， 55 BC for read port0;
55 C1 for write Port1 ， 55 C3 for read port1;
55 C2 for write Port2 ， 55 C4for read port2(Port2 only for-500).
2. For further information, see <USR-TCP232-XX config protocol V3.doc>.
4.3.
4.3.
4.3.
4.3. network
network
network
network command(setup
command(setup
command(setup
command(setup software)
software)
software)
software)
1. through software USR-TCP232-E45 Setup V1.0.5.0;
2. Network command(need to ask for protocol before purchasing).
Downbelow is the Setup for USR-TCP232-E45, http://www.usr.so/Download/90.html
http://www.usr.so/Download/90.html
http://www.usr.so/Download/90.html
http://www.usr.so/Download/90.html
