UTT Technologies Application
http://www.uttglobal.com Page 36
Figure 4-15 2.4GHz wireless setting
Enable Wireless: Click to enable 5GHz Wireless network. When the wireless network is bad,
you can click 1-click Optimization to optimize the network.
SSID 1 or SSID 2: The SSID (Service Set Identification) is also known as the wireless network
name, which is used to uniquely identify a wireless network.
Hidden SSID: Select to hidden SSID. In this case, if users want to access this network, they
need to search for SSID by entering it manually.
SSID ISOLATION: Select the SSID you want to isolate from the drop-down box, available
options are No ISOLATION, ISOLATE SSID1 and ISOLATE SSID2.
No ISOLATION: if selected, all users connected to the Device can access to the Device.
ISOLATE SSID1: if selected, the users connected to SSID 1 couldn’t access to the Device.
