16 vacon monitoring & parameters
Tel. +358 (0)201 2121 • Fax +358 (0)201 212205
5
5.3 Motor settings (Control panel: Menu PAR -> P1)
Code Parameter Min Max Unit Default ID Note
Motor nominal
voltage
180 690 V Varies 110
Check rating plate on the
motor
Motor nominal fre-
quency
30,00 320,00 Hz
50,00 /
60,00
111
Check rating plate on the
motor
Motor nominal
speed
30 20000 rpm
1440 /
1720
112
Default applies for a 4-pole
motor
Motor nominal
current
0,2 x
I
Nunit
2,0 x
I
Nunit
A
I
Nunit
113
Check rating plate on the
motor
Motor cos
(Power Factor)
0,30 1,00 0,85 120
Check rating plate on the
motor
Current limit
0,2 x
I
Nunit
2,0 x
I
Nunit
A
1,5 x
I
Nunit
107 Maximum motor current
Motor control
mode
01 0600
0 = Frequency control
1 = Open loop speed control
U / f ratio 0 2 0 108
0 = Linear
1 = Square
2 = Programmable
Field weakening
point
8,00
320,00 Hz
50,00 /
60,00
602
Field weakening point fre-
quency
Field weakening
point voltage
10,00 200,00 % 100,00 603
Voltage at field weakening
point as % of U
nmot
U / f mid point
frequency
0,00 P1.10 Hz
50,00 /
60,00
604
Mid point frequency for
programmable U / f
U / f mid point
voltage
0,00 P1.11 % 100,00 605
Mid point voltage for pro-
grammable U / f as % of
U
nmot
Zero freq voltage 0,00 40,00 % 0,00 606
Voltage at 0 Hz as % of
U
nmot
Torque Boost 0 1 0 109
0 = Disabled
1 = Enabled
Switching fre-
quency
1,5 16,0 kHz 4,0 / 2,0 601
PWM frequency. If values
are higher than default,
reduce the current capacity
Brake Chopper 0 2 0 504
0 = Disabled
1 = Enabled: Always
2 = Run state
Table 5.3: Motor settings
P1.1
P1.2
P1.3
P1.4
P1.5
P1.7
P1.8
P1.9
P1.10
P1.11
P1.12
P1.13
P1.14
P1.15
P1.16
P1.17
