APPENDIX B
Special Actual Values
By default, the Actual Value corresponds to the motor rotation speed in percentage.
Actual Value can be attached some other monitored variable. Meaning of Actual Value can be selected
by resetting a Control Word bits 15...11. The user can choose to show one of the monitoring page
variables or the active fault code.
Control Word (bits 15...11) is binary coded as follows:
Control Word Description
bit 15 bit 14 bit 13 bit 12 bit 11
0 0 0 0 0 Default, Actual Speed (%)
0 0 0 0 1 V1 (see table 0-1)
0 0 0 1 0 V2 (see table 0-1)
0 0 0 1 1 V3 (see table 0-1)
.
.
1 1 1 0 1 V29 (see table 0-1)
1 1 1 1 0 Active Fault Code
1 1 1 1 1 Default, Actual Speed (%)
NOTE: The minimum interval allowed to change the bits above is 500ms!
# Data name Step Unit Description
V1 Output frequency 0,01 Hz Frequency to the motor
V2 Motor speed 1 rpm Calculated motor speed
V3 Motor current 0,1 A Measured motor current
V4 Motor torque 1 % Calculated actual torque/nominal torque of the
unit
V5 Motor power 1 % Calculated actual power/nominal power of the
unit
V6 Motor voltage 1 V Calculated motor voltage
V7 DC-link voltage 1 V Measured DC-link voltage
V8 Temperature 1 °C Temperature of the heat sink
V9 Operating day count DD.dd
Operating days
1)
, not resetable
V10 Operating hours, "trip
counter”
HH.hh
Operating hours
2)
, can be reset with program-
button #3
V11 MW-hours 0,001 MWh Total MW-hours, not resetable
V12 MW-hours, "trip
counter"
0,001 MWh MW-hours, can be reset with programmable
button #4
V13 Voltage/analogue
input
0,01 V Voltage of the terminal U
in
+ (control board)
V14 Current/analogue
input
0,01 mA Current of terminals I
in
+ and I
in
- (control board)
V15 Digital input status,
gr. A
0 = Open Input, 1 = Closed Input (Active)
V16 Digital input status,
gr. B
0 = Open Input, 1 = Closed Input (Active)
V17 Digital and relay
output status
0 = Open Input, 1 = Closed Input (Active)
V18 Control program Version number of the control software
V19 Unit nominal power 0,1 kW Shows the power size of the unit
V20 Motor temperature
rise
1 % 100%= temperature of motor has risen to nominal
value
1)
DD = full days, dd = decimal part of a day
2)
HH = full hours, hh = decimal part of an hour
