VACON CX Profibus user’s manual Page 19
________________________________________________________________________________________
________________________________________________________________________________________
Vacon Oyj Phone +358-201-2121 Fax: +358-201-212 205
7.4 Parameter Data
Fieldbus Board VACON CX
P PARAMETERS
Parameters
R
Out
p
ut
O
Parameter ID
F
Parameter Index
I
Parameter Value Variables
B
In
p
ut
U
Parameter ID
S
Parameter Index
Parameter Value
A
ctive Fault Code
D
P
M
A
S
T
E
R
The Vacon variables and fault codes can be read and parameters can be read and written using PPO
types 1 and 2.
7.4.1 Actual Values
Actual Values can be read by using the parameter read function.
Profibus parameter numbers according to monitored item numbers are as follows.
Parameter number Vacon variable
1 n1
2 n2
. .
. .
98 n98
Number Data name Step Unit Description
V1 Output frequency 0,01 Hz Frequency to the motor
V2 Motor speed 1 rpm Calculated motor speed
V3 Motor current 0,1 A Measured motor current
V4 Motor torque 1 % Calculated actual torque/nominal torque of the unit
V5 Motor power 1 % Calculated actual power/nominal power of the unit
V6 Motor voltage 1 V Calculated motor voltage
V7 DC-link voltage 1 V Measured DC-link voltage
V8 Temperature 1 °C Temperature of the heat sink
