DISPLAYS 32
Browsing through the individual pages takes place by pressing the button [SCROLL].
Display Explanation
Error histogram - the last 10 errors are stored here. The upper
line changes between error histogram and the real fault number
with a relative time stamp referenced to the operating minutes.
The lower line displays the error in plain text.
Display Explanation
Minimum and maximum value of the intermediate circuit volt-
age.
Display Explanation
Minimum and maximum motor current in [A/10]
Display Explanation
Minimum and maximum output stage temperature in [°C]
Display Explanation
Average output stage temperature in [°C]
