TECHNICAL DATA 20
5 TECHNICAL DATA
Information Basis Description
Conformity and approval
CE 2014/35/EU Low voltage directive
2014/30/EU EMC directive
Person and equipment protection
Protection class EN60529 IP54
All plug connectors that are not in use must
be closed with protective caps or blind plugs.
The USB cover screw connection must be
available.
Earth leakage current EN61800-5-1 < 3.5mA
Insulation (control circuits) EN61800-5-1 Safe separation from the grid through dual
(reinforced) insulation.
Insulation strength EN61800-5-1 < 2000m installation height: Overvoltage
category III
> 2000m installation height: Overvoltage
category II
Protective measures Against motor overtemperature (input PTC
or thermal contact), overcurrent at the out-
put
EMC
Interference emission EN61800-3 Adherence to the limit values for the second
environment (industrial area): Category C3
Interference resistance EN61800-3 Adherence to the limit values for the second
environment (industrial area): Category C3
Ambient conditions
Climatical
Storage IEC/EN60721-3-1 1K3 (-25 ... +70°C) < 6 months
1K3 (-25 ... +40°C) > 6 months
> 2 years - forming intermediate circuit ca-
pacitors
Transport IEC/EN60721-3-2 2K3 (-25 ... + 70°C)
100% switch-on time IEC/EN60721-3-3 3K3 (-10 ... +45°C)
0 ... +40°C
70% switch-on time 3K3 (0 ... +50°C)
+40 ... +50°C reduce the rated output cur-
rent by 2.5%/°C.
Installation height < 4000m NHN
> 1000m reduce the rated output current by
5%/1000m
Mechanical vibration resistance
Storage Germanischer Lloyd Vibration test 1
Transport EN60721-3-2 2M2
