Property Specification
Output current min. 1.3 A
Output connector Locking type female coaxial connector with
positive 2.0 mm center pin
Operating temperature range -20 ... +60 °C (-4 ... +140 °F)
Operating humidity range 0 ... 95 %RH, non-condensing
Certifications and approvals • Certified to IEC 60950-1 or IEC 62368-1
• Approved for use in your country
2.7 Remote Management
AP10 has a web interface for remote management. Additionally, some settings can be
remotely managed using viewLinc Enterprise Server software. Remote management
operations can be performed directly from the Sites Manager > Hosts and Devices tree.
Figure 5 AP10 Remote Management using viewLinc Enterprise Server
AP10 User Guide M211860EN-A
12
