Property Specification
Operating temperature -20 ... +60 °C (-4 ... +140 °F)
Operating humidity 0 ... 90 %RH, non-condensing
Storage temperature -20 ... +60 °C (-4 ... +140 °F)
Table 8 Inputs and Outputs
Property Description/Value
Operating voltage using dedicated power
supply connector
10 ... 30 VDC
PoE power class Class 0
Power consumption Max. 13 W
Internal clock Synchronizes with Network Time Protocol (NTP)
server
Supported devices Up to 32 VaiNet compatible data loggers
Compatible viewLinc versions 5.0 and above
User interfaces Web browser interface
Local touchscreen interface
User interface languages English, German, French, Portuguese, Spanish,
Swedish, Chinese, Japanese
Ethernet Interface
Supported standards 10BASE-T, 100BASE-TX
IPv4 address assignment DHCP (automatic), static
Connectors
Power supply connector 2.0 mm center pin locking type DC power jack
Service port Micro-USB (2.0)
Expansion port USB type A (2.0)
Ethernet 8P8C (RJ-45)
Table 9 Mechanical Specifications
Property Specification
IP rating IP30
Housing color White
Mounting methods Screws, tie-wrap
AP10 User Guide M211860EN-A
40
