3. A setup wizard starts when AP10 is first powered up. Use the touch interface to complete
the wizard:
a. Select a language for the touchscreen display.
b. Configure the network settings so that AP10 can join the network.
c. Configure the Network Time Protocol (NTP) servers that the access point will attempt
to synchronize with. If you have a local NTP server in the network, replace one of the
default NTP server hostnames with its IP address or hostname.
d. Select a VaiNet channel (1 ... 8). Each access point in range of each other must have a
unique channel assigned to it.
e. Enter the IP address or hostname of the viewLinc Enterprise Server. Leave the TCP
port at default 12600 unless you know it has been changed.
f. Enable Installation Mode to start connecting data loggers to your system.
4. After the setup wizard is complete, wait for the display to change to the home screen
where you can see the status of the access point at a glance.
An NTP connection error continues to be shown while AP10 is synchronizing
time with the listed NTP servers. It may take up to 15 minutes for it to
disappear even when the NTP servers are reachable. Wait patiently.
To change the configuration of the access point, touch the symbol to
open the Settings screen.
3.3 Mounting AP10
• AP10 Access Point, set up and configured
• Content of AP10 delivery package
• Crosshead screwdriver (if screw mounting is used)
AP10 User Guide M211860EN-A
20
