Valmet MCA - Page 11

1
2
3
4
5
6
7
8
9
10
Fig. 4. Valmet MCA-FT construction drawing: 1. Sensor Cover, 2. Sensor Electronics, 3. Base Plate Assembly,
4. Pt-100 Thermoelement, 5. Sensor Body, 6. Antenna Sealing, 7. Microwave Antenna, 8. Antenna Flange, 9.
Antenna Cable, 10. Antenna Cover.
Installation & Owner’s manual OUL00298 V2.3 EN
11
Valmet Mircowave Consistency Transmitter
