Valor 534XAP User Manual

4040
Venting Parts Description
Venting Parts Code / Availability by Manufacturer
SIMPSON
DURA-VENT
SELKIRK
SECURE
VENT
RLH
INDUSTRIES
MILES
INDUSTRIES
DV 45°
Elbows
Galvanized 945 — — —
——
Black 945B — — SV4EBR45
Galvanized Swivel 945G 4DT-EL45
—
SV4E45
— —
Black Swivel 945BG 4DT-EL45(B) SV4EB45
DV 90°
Elbows
Galvanized 990 — — —
— —
Black 990B — — SV4EBR90
Galvanized Swivel 990G 4DT-EL90
—
SV4E90
— —
Black Swivel 990BG 4DT-EL90(B) SV4EB90
Pipes 4” x 6 5/8” ( ID x OD )
6” long
Galvanized 908 4DT-06
—
SV4L6
— —
Black 908B 4DT-06(B) SV4LB6
9” long
Galvanized 907 4DT-09
—
—
——
Black 907B 4DT-09(B) —
12” long
Galvanized 906 4DT-12
—
SV4L12
— —
Black 906B 4DT-12(B) SV4LB12
18” long
Galvanized 4DT-18
—
—
——
Black 4DT-18(B) —
24” long
Galvanized 904 4DT-24
—
SV4L24
——
Black 904B 4DT-24(B) SV4LB24
36” long
Galvanized 903 4DT-36
—
SV4L36
——
Black 903B 4DT-36(B) SV4LB36
48” long
Galvanized 902 4DT-48
—
SV4L48
——
Black 902B 4DT-48(B) SV4LB48
Flashing
Roof Flashing
0/12-6/12
943 4DT-AF6 — SV4FA — —
Roof Flashing
7/12-12/12
943S 4DT-AF12 — SV4B — —
Flat Roof Flashing 943F — — SV4F — —
Various Venting System Parts
Wall Thimble 942 4DT-WT — SV4RSM — —
Storm Collar 953 4DT-SC — SV4AC — —
Decorative Plate 940 4DT-CS — SV4PF — —
Cathedral Ceiling
Support
941 4DT-CCS — — — —
Ceiling Firestop / Floor
Support
963 4DT-FS —
SV4BF
— —
SV4SD
Wall Strap 988 4DTWS — — — —
Vinyl Siding Standoff 950 4DT-VS — SV4VS — —
Elbow Strap 989 4DT-OS — — — —
Terminal Guard 984SG — — — — 835TG
Notes: 1) Simpson Dura-Vent co-axial pipes and fi ttings require Valor 817VAK Starter Adapter to fi t Valor’s smooth collars. All other above
manufacturers’ collars will fi t directly to Simpson Dura-Vent or Valor’s smooth collars. 2) Follow instructions supplied with each manufacturer’s
components. 3) Unless otherwise specifi ed, all the parts and assemblies from the above table are to be used with 4” x 6-5/8” pipes.
4) Termination caps manufactured by RLH Industries are from Homestyle Chimney Collection and can be ordered in one of the following
fi nishes: a) aluminium; b) black powder coated; c) solid copper.
Approved Venting Components
