Specifi cations
Approvals & codes
These appliances are certifi ed by ANSI Z21.88-2007 / CSA 2.33-2007 Vented Gas Fireplace Heater for use in Canada
and USA. These appliances are for installation directly venting through an outside wall or through the roof.
Model 534XAN is for use with natural gas.
Model 534XAP is for use with propane gas. It can be converted for use with natural gas with kit #607NGK.
These appliances comply with CGA P.4.1 Testing method for measuring annual fi replace effi ciencies.
The installation must conform with local codes or, in the absence of local codes with the National Fuel Gas Code, ANSI
Z223.1 or the Natural Gas and Propane Installation Code CAN/CGA-B149. Only qualifi ed licensed or trained personnel
should install these appliances.
These appliances, when installed, must be electrically grounded in accordance with local codes or, in the absence of local
codes, with the National Electrical Code, ANSI/NFPA 70 or the Canadian Electrical Code, CSA C22.1.
*Tested to CAN/CGA - 2.17 Gas fi red appliances for use at high altitudes. In the USA, installations may require
deration over 2000’—check local codes.
Wall Thickness
The vent system (when horizontally terminated) is approved to pass through combustible wall construction of up to
14” (36 cm) thick.
A non-combustible wall can be any thickness up to the maximum horizontal run of vent pipe allowed for the
particular installation—see Location section.
Model 534XAN 534XAP
Gas Natural Propane
Altitude (Ft.) 0-4500 *
Input Max. (Btu/h) 24,000 24,000
Input Min. (Btu/h) 6,500 13,000
Manifold pressure (in w.c..) 3.8 – 4.2 9.3 – 9.7
Min. Supply pressure (in. w.c.) 5.0 11.0
Max. Supply pressure (in. w.c.) 10.5 14.0
