Vanderbilt VR4 S-MF Series User Manual

2 Technical data
2 Technical data
VR10S-MF Mifare card reader
standard
VR11S-MF Mifare card reader
standard incl. UK adapter plate
and extension cable
VR40S-MF Mifare card reader
standard with keypad and display
VR41S-MF Mifare card reader
standard with keypad and display
standard incl. UK adapter plate
and extension cable
Protocol OSDP OSDP
Interface to controller RS485 RS485
Operating voltage 8.5 – 30.0 VDC 8.5 – 30.0 VDC
Power consumption DC 12V 43mA Peak 168mA
DC 24V 26mA Peak 100mA
DC 12V 60mA Peak 220mA
DC 24V 40mA Peak 125mA
Tamper protection Yes Yes
Card technology Mifare Mifare
Card compatibility Mifare Classic
Mifare Plus
Mifare DESfire EV1
Mifare Classic
Mifare Plus
Mifare DESfire EV1
Reading distance Up to 6 cm Up to 6 cm
Indicators 3 x LED (red/yellow/green)
1 x Buzzer
Multicolor light frame
3 x LED (red/yellow/green)
1 x Buzzer
Multicolor light frame
Keypad No Yes
Display No Yes, graphic monochrome OLED
Operating temperature - 40°C to + 55°C* - 40°C to + 55°C*
IP rating IP55** IP55**
IK class 08 08
Housing Zinc casted metal bezel with
polycarbonate plastic front
Zinc casted metal bezel with
polycarbonate plastic front
Color Black, matt chrome Black, matt chrome
Dimensions (W x H x D) Surface mounted: 85 x 114 x 22
Back box mounted: 85 x 114 x 14
Surface mounted: 85 x 114 x 22
Back box mounted: 85 x 114 x 14
Approvals CE according to R&TT and EMC
Directives
CE according to R&TT and EMC
Directives
* Only applicable for surface mounted readers. Back box mounted readers are specified from -10°C to +55°C.
** Only applicable for surface mounted readers. Back box mounted readers are specified to IP3X.
5
Vanderbilt International (IRL) Ltd. 2017-04-12
