Installation
- 14 - IQ SERIES OWNERS MANUAL
2.1 (1) INVERTER Indicator Light
Light Action Description
Green Light is OFF Inverter circuit is OFF
Solid Green Inverter is ON (producing AC power)
Fast Blinking Light Inverter is in Load Demand Mode
(2 blinks per second)
IQC Models (Inverter/Charger) in Charger Mode (This is when shore power to AC1 is ON.)
Slow Blinking Light Shore power is supplying AC power to the loads.
(1 blink per second)
2.2 (2) ON/OFF Switch
The ON/OFF switch is a three-position rocker switch whose function is similar to the ignition switch on a
vehicle. The low position is OFF/RESET. The middle position is ON (RUN). The high position is START,
which is a momentary position.
IQ Models and IQC Models in Inverter Mode (This is when shore power is OFF.)
OFF In the OFF position the inverter is locked OFF. The indicator lights do not function and
the inverter cannot be started from a remote switch. (Please note that this does not
disconnect power from the inverter system.) Approximately 50ma is being drawn from the
battery.
ON (RUN) The switch must be in the ON (RUN) position for the inverter to be operational and for
remote switch capability to be enabled.
START Press the switch to the START position to start inverter operation.
RESET If the inverter has turned itself OFF due to overload or low battery, the switch must be
moved to OFF/RESET before the inverter can be restarted.
IQC Models (Inverter/Charger) in Charger Mode (This is when shore power is ON.)
OFF In the OFF position the charger is locked OFF. The indicator lights do not function and
the charger cannot be started from a remote switch. (Please note that this does not
disconnect power from the inverter system.) No power is being drawn from the battery.
Power on AC input is being monitored for proper voltage and frequency but power will not
be accepted for charging or passthrough.
ON (RUN) The switch must be in the ON (RUN) position for the charger to be operational and for
remote switch capability to be enabled.
